Vacuum Chambers
The TC-280



 Ideal for all medical, electronic, food
and industrial applications!


  Features:
  Polished 316 Stainless Steel Construction
  BUSCH vacuum pump
  Removable sealing bar
  Transparent Lid
  Available with PLC/TouchScreen for all Medical Applications

  Technical Data Sheet :
  Sealing length:11" (280mm)*1
  Chamber height: 3.15" (80mm)
  Chamber size:11.4" (290mm) x 13.4" (340mm) (L x W)
  Sealing bar distance:12.2" / 310mm
  Vacuum pump capacity:4m3/h
  Cycle Time: 10-25 Sec
  Machine size: 17.24" (438mm) x 12.5" (317mm) x 11.5" (293mm) (L x W x H)
  Voltage: 110v or 220v
  Power: 0.2kw
  Weight: 88 lbs. (30 kg)
